Hotel Packaged Terminal AC - PTAC

Introduction:

The packaged terminal air conditioner or PTAC is a packaged type air conditioner mounted through a wall or fit under a window in hotels, motels, hospitals, apartments, etc. It has both heating and cooling functions with capacity values range from 7,000–19,000 BTU. It can be inverter type or on-and-off type.

PTAC
hotel-ptac

Inverter Type PTAC:

  • High Energy Efficiencies: Efficient refrigeration design with EER up to 12.1 and COpup to 3.5,meeting the latest AHRl standard and DOErequirement.

  • Silent Design: Optimized air discharge channel design,specialized blowerwheel, bigger diameter Ф120*700mm,lower rotationalspeed, all contributing lower noise level. Indoor noise level(L/H) can be low to 36/45 dB(A). Efficient rotary compressor mounted with vibration isolators to keep the compressor running smoothly and quietly.

inverter-PTAC
ptac-high-efficiency-and-silent-running

Inverter Type PTAC:

  • Room Freeze Protection: When indoor room temperature has fallen to 50°F,the unit will cycle on the fan and run electric heatingmode to raise the room temperature to 55°.

  • Self Diagnostics: Our units have function of self check error. Also error code will show on electric display.

  • Easy Installation And Maintenances: Indoor and outdoor sub assembly structure, integral type chassis structure, whole form air discharge channel, as well as sealed electric PCB box make installation and maintenance more convenient. Nylon mesh filter is easily dismantled and a filter bag can be be put in front of it if you need.

easy-installation-ptac

Inverter Type PTAC:

  • Wall Sleeve: AII our wall sleeves have industry standard dimensions of 42"wide X 16"high. The 14"depth is the industry standard. Sleeves may be shipped separately to allow for installation during construction.

  • Outdoor Grille: Available in stamped aluminum louvered for application with wall sleeve.

  • Condensate Drain Kit (Optional): Attached to the wall sleeve base ban to control the disposal of condensate water.

  • Instant Heat Mode: Heat pump models will automatically run the electric heater to quickly bring the room up to temperature when initially energized, then return to heat pump mode.

  • Factory Run-test: A series of tests will be taken before shipping to reduce problems when in use.

  • Standard E-heater.

ptac-wall-sleeve-grille
instant-heat-mode-ptac

Inverter Type PTAC:

  • The Widest Cooling & Heating Range With Three Models: Variable speed technology gives you the flexibility of a full line of PTACs with three models, and offers the highest available capacity of any 42 x16 PTAC on the market at over 17000 Btu.
    9K Model
    Can operate as low as 5250 Btu/h and as high as 11900 Btu/h.
    12K Model
    Can operate as low as 5300 Btu/h and as high as 14300 Btu/h.
    15K Model
    Can operate as low as 7000 Btu/h and as high as 17140 Btu/h.

  • High Efficiency DC Inverter Mitsubishi Rotary Compressor: Better dehumidification; Variable speed inverter for saving more energy; Quieter start-up and operation safely and reliably; Reduced temperature swings improve guest comfort; High temperature control accuracy and precise adjustment; Better efficiency during part load hours of cooling & heating.

  • Low Starting Current: Lower starting current,reduce the impact on the power grid,safer and more reliable than traditional ones.

  • Inverter PTAC Delivers Best-in-class Efficiencies And Low Sound Levels: Inverter units with inverter compressors deliver equivalent EER up to 11.7, SEER up to 15.0,IEER up to 18.64,application HSPF up to 11.57; and offer many advantages over traditional PTACs.

ptac-performance
inverter-ptac-efficiency
inverter-ptac-structure
inverter-ptac-specification
PTAC-through-the-wall
ptac-specification
26-inch-ptac

Through The Wall: 26in Room Air Conditioner

  • High Energy Efficiency: The unit meet the latest efficiency requirement.

  • Compact Design: The unit has the industry standard size of 26"x15.6" designed to easily be installed in most standard wall sleeves such as in bedroom, hotel and office building.

  • Combined Panel: The newly designed combined panel provide an access to replace or clean filter. Also filter bags can be put in front of the filter.

  • 3D Airflow: The discharge grille can be adjusted to expel air at either a 15｡or 55｡angle. The discharge air flow can be easilydirected toward any areas in room.

  • Silent Design: Indoor fan motor has three fan speed with low noise level. Outdoor fan motor has two fan speed. Also a
    damping installed on compressor contribute to a lower noise. Choosing sleeping mode, a low fan speed can
    provide a comfortable environment and save energy.

  • Electric Heater In Priority ( Optional ): Choose electric heating in priority mode by dialing the switch and the room temperature will rise to a comfortable level in less time than heat pump heating mode.

  • Special Design for Outdoor Fan: Under cooling mode, axial-flow fan with circling drived by outdoor fan motor spin condensed water to the condenser, providing a greater performance.

  • Self Diagnostics: The unit has function of self check error, meanwhile all units can tolerate error internally and automatically restore memory when restart. Also error code will show on electric display.

  • Easy Maintenance: Air flter is easy to move out and clean, preventing dust blocking the air flow and making air fresher.

ptac-panel
ptac-accessory
through-wall-ptac-parameters
